Best Quality 300GSM PP/Polyester Non

Basic Info.

Model NO.	DBJX--Geotextiles
Width	1-6m
Tearing Strength	0.08-0.6kn
Elongation at Break	25-100
Length	50-100m/Roll (at Request)
Weight	100-800G/M2
Thickness	5mm
Transport Package	Packed in Roll with PP Woven Bag
Specification	Gsm: 100-800
Trademark	Haisan
Origin	Qingdao, China
HS Code	5603939000
Production Capacity	100000 Square Meters Per Month

Product Description

Best Quality 300GSM PP/Polyester Non-Woven Geotextile with Ce/ISO9001

Product Introduction:
Short fiber knitting geotextile takes the polypropylene fiber or the polyester fiber short fiber as the primary material,after blooms the pine, to comb, disorderly,craft productions and so on shop net, acupuncture to become.
Technical Parameters :

Specification	100	150	200	250	300	350	400	450	500	600	800	Remark
Quality deviation per unit acreage%	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6
Thickness,mm≥	0.9	1.3	1.7	2.1	2.4	2.7	3.0	3.3	3.6	4.1	5.0
Width deviation for range,%m	-0.5
Mightiness at break,KN/m ≥	2.5	4.5	6.5	8.0	9.5	11.0	12.5	14.0	16.0	19.0	25.0	Vertical and horizontal
Elongation at break,%	25-100											Vertical and horizontal
CBR bursting strengthk,KN≥	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.2	4.0
Effective aperture O90(O95)mm	0.07-0.20
Vertical osmotic coefficient,cm/s	K x(10-1-10-3)											K=1.0-9.9
Tearing strength, KN≥	0.08	0.12	0.16	0.20	0.24	0.28	0.33	0.38	0.42	0.46	0.60	Vertical and horizontal

Detailed images:
Product features:

*Net holes are easy for net blockage, since net structure formed by indefinite fider has variable and motility.

*It has high permeation and can keep good permeation under the pressure of earthwork.

*It has corrosion resistance, uses chemical fiber such as polypropylene or Dacronas raw material, has acid andalkali resistance, hasn't corrosion or moth eating and has oxidation resistance.

*It has convenient construction, small weight and convenient uses.
Application :
*It isolates building materials with different physical features, makes two or multiple materials with outerosion ormixing, keeps overall structure and functions of material and makes load bearing capacity of structure strengthen.

*When water flows into coarse soil layer from soil layer, it uses good gas and water permeation of knittinggeotechnical geotextile, allows water flow to pass and effectively holds back soil particle, fine sand andsmallstone so as to keep stability or water conservation project.

*Itis good water guide material, and can form drainage channel in soil body and remove excessive liquid andgas from soil structutre.

*It uses knitting geotechnical cloth to strengthen tension resistance strength and deformation capacity of soilbody, to strengthen stability of structure and to improve soil body quality.

*It effectively diffuses, transmits or decomposes central stress and prevents soil body damage by functioningof external force.

*Knitting geotechnical cloth matches other materials and forms nonpermeation

Isolation layer.

Market:

Service team:

Our services:
1Reply your inquiry in 24 working hours.

2Experienced staffs answer all your questions in fluent English

3Special discount and protection of sales are provided to our distributor.

4Sample:we can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side,the charges will be rebounded when we haveformal order.

5Professional factory: We are manufacturer,specializing in producing all kinds of geogrids for more than 10 years, competitive with good quantity.

6As an honest seller, we always use superior raw material, advanced machines,skilled technicians to ensure our products to be finished in high quality and stable feature.

Contact:

Qingdao Haisan New Energy Co.,Ltd.

Website: haisan.en.made-in-china.com
Name :Grace Sun
FAQ:

Q1. May I have the sample for testing?

A:Yes, we are glad to provide free samples within 1 week.

Q2.Can we use our own logo or design for sticker?

A:Yes,you can , you can contact with the salesman, please send an email to her /him and tell.

Q3.What certification do you have?

A:CE,ISO9001/ISO14001/OHSAS18001 etc.
