China Manufacturer PP/Pet Nonwoven Needle Punched Fabric Geotextile for Lake Road Construction

Basic Info.

Model NO.	Non Woven Geotextile
Certification	CE
Feature	Corrosion Resistant, Oxidation Resistance, Wear-resistant
Usage	Insulation, Waterproof, Water Filter
Material	PET
Kind	Non-woven
Length	50-300m
Quality	CE/ASTM/GM Available
Width	1-6m
Elongation	<100%
Transport Package	Rolled
Specification	80-1000g
Trademark	Dageng
Origin	Shandong
HS Code	5603941000
Production Capacity	50000 Square Mater Per Day

Packaging & Delivery

Package Size 580.00cm * 40.00cm * 40.00cm Package Gross Weight 100.000kg

Product Description

Product Introduction:
Usually, non woven geotextile refers to needle punched non-woven geotextile made from Polyester or polypropylene short curing fiber with the diameter of 6D to 12D and length of 54-64mm.The producing process is to opening, carding and cluttering the short fibers to make them cross with each other, and then lapping to let the fibers normalize entangling, and at last needle punched with high speed. It is an effective and economical solution of separation, filtration, drainage, protection and reinforcement functions for engineering projects.
Application:
For Filtration:
When water passes from a fine-grained to a coarse grained layer, Non woven Geotextile can retain fine particles well. For an example, when water flows from a sandy soil into a Geotextile wrapped gravel drain.For Separation:It can separate two layers of soil with different physical properties. For an eample, the separation of road gravel from soft sub-base materials.For Drainage:It can drain liquid or gas from the plane of the fabric, which leads to draining or venting of the soil. For an example, the gas vent layer in a landfill cap.For Reinforcement:It can improve the load bearing capacity of a specific soil structure. For an example, the reinforcement of a retaining wall.
Package and delivery:Package: Inner pipe + outside bag or film.Delivery: 10 containers per month.

PP Short Fiber Needle Punched Nonwoven Geotextile: CE Certificate
Gram Weight g/m2	100	150	200	250	300	350	400	450	500	600	800
Tolerance of unit weight %	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6
Thickness mm≥	0.9	1.3	1.7	2.1	2.4	2.7	3	3.3	3.6	4.1	5
Tolerance of roll width %	-0.5
Breaking strength KN/M ≥	5.5	8	11	13.5	16	18.5	22	24.5	28	34	40
Elongation %	50-90
CBR bursting strength KN ≥	0.15	0.45	0.5	0.6	0.7	0.8	0.9	1.1	1.3	1.6	2
Tearing strength KN≥	0.45	0.65	0.9	1.1	1.25	1.4	1.6	1.8	2	2.2	2.4

PP High Strength Short Fiber Non woven Geotextile: CE Certificate
Weight g/m2	100 (15%)	200 (16%)	300 (16%)	400 (16%)	500 (16%)	600 (16%)	800 (16%)	1000 (16%)
Thickness mm	1.4-1.7	1.8-2.2	2.4-2.8	3-3.5	3.6-4	4-4.4	4.8-5.2	5.6-6
Grab Tensile Strength N≥	450	900	1250	1600	2000	2400	3000	3600
Elongation %	50-90			50-100
Trapezoidal Tear N≥	175	350	425	500	580	650	800	950
CBR Puncture Resistance KN≥	1.25	2.5	3.5	4.3	5.3	6.2	7.1	8
Breaking Strength KN≥	5.5	11	16	22	28	34	45	55
Elongation at breaking %	40-65			50-80
Puncture Strength N ≥	220	430	665	900	1200	1430	1900	2350
Peel Strength N/5cm≥	80			100
Resistance to Acid and Alkali %	The Breaking Strength Resistance Rate ≥90%; Breaking elongation resistance rate ≥90%.
Equivalent Aperture (Dry sieve ) mm	≤0.1
Vertical Permeability Coefficient cm/s	≤0.2

Polyester Short Fiber Needle Punched Nonwoven Geotextile: CE Certificate
Gram Weight g/m2	100	150	200	250	300	350	400	450	500	600	800
Quality deviation per unit acreage %	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6
Thickness mm≥	0.9	1.3	1.7	2.1	2.4	2.7	3	3.3	3.6	4.1	5
Width deviation for range, % m	-0.5
Mightiness at break, KN/M ≥	2.5	4.5	6.5	8	9.5	11	12.5	14	16	19	25
Elongation at break, %	25-100
CBR bursting strength, KN ≥	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.2	4
Effective aperture O90	0.07-0.20
Vertical osmotic coefficient,cm/s	K*(10-1-10-3), K=1-9.9
Tearing strength, KN≥	0.08	0.12	0.16	0.2	0.24	0.28	0.33	0.38	0.42	0.46	0.6

FAQ:
Q: Are you factory or trading company?
A: We are factory
Q: Which country did you export? A: Our products have been exported to many countries all over the world, including USA, Panama, Colombia, Chile, Peru, Ecuador, Russia, UK, Italy, France, Germany, Poland, Hungary, Turkey, Romania, Israel, India, Philippines, Singapore, Vietnam, Thailand, Indonesia, Australia, New Zealand... Q: May I have your samples for testing?
A: Yes. We are glad to provide free samples within 3 days. Q: What is your MOQ?
A: Normally, MOQ is one 20'GP container. But we also accept LCL for trial order
Q: What's the payment term?

A: T/T,L/C.
